Architects and engineers working on existing buildings have a problem that's deceptively simple to describe and surprisingly expensive to solve badly: they need to know exactly what's there before they can design what comes next.
Floor plans from the original build are a starting point, not a reliable record. Buildings get modified. Partitions move. Services get rerouted. Dimensions shift. By the time a design team is working on a refurbishment or change-of-use project, the gap between what the drawings say and what's actually there can be significant — and consequential.
The right survey methodology depends on what the design team actually needs to produce. And that's a question worth asking carefully, because the answer differs depending on the project.
Two Different Tools for Two Different Purposes
There is a meaningful technical difference between the two main outputs from a professional site survey, and conflating them leads to either overspending on capability you don't need or undershooting on accuracy and getting data you can't use.
Navigable Digital Twin
The kind produced by Matterport Pro3 — a photorealistic, explorable 3D model of the space. Extraordinarily useful for client presentations, remote site review, coordination between dispersed project teams, and conditions documentation. Measurements can be taken within the model. It's accurate enough for spatial planning and general design intent. It is not, however, survey-grade. There is inherent spatial drift across large spaces that makes it unsuitable as the primary data source for precision CAD or Revit modelling.
Survey-Grade Point Cloud
Produced by LiDAR scanners calibrated for accuracy and registered using control points — delivers spatial data to within 5–12mm across a full building footprint. It exports in formats (.e57, .rcp, .pts) that plug directly into AutoCAD, Revit, and other BIM workflows. Architects can trace floor plans directly from the data. Structural engineers can verify existing dimensions with confidence. M&E consultants can model around existing services without assumptions.
The question isn't which is better. It's which is right for what you're designing.
When Each Approach Is Appropriate
Navigable digital twin
The right deliverable when the primary need is spatial understanding, remote access, conditions documentation, and team coordination. For QSR rollouts, pre-acquisition due diligence, asset management, and multi-site programmes, this is typically exactly what's needed.
Survey-grade point cloud
The right deliverable when design work requires dimensional accuracy that will be relied upon for structural, services, or architectural decisions. Refurbishment projects, change-of-use schemes, heritage building surveys, and complex MEP coordination all typically require this level of accuracy.
Both
Many projects need both — the navigable twin for the client and the project team, the point cloud for the design consultants. This is increasingly the standard for well-resourced refurbishment projects.
What Survey-Grade Point Cloud Data Actually Enables
When a design team receives properly registered point cloud data, they can:
Produce accurate as-built floor plans, sections, and elevations without a single manual measurement taken on site
Model existing structural elements, columns, beams, and slab profiles in Revit with dimensional confidence
Coordinate new MEP routes around existing services
Identify existing building tolerances and deviations from nominal before fabrication decisions are made
Produce planning and listed building consent drawings from accurate spatial data
The alternative — designing from manually measured drawings with estimated or assumed dimensions — is a source of consistent downstream error that compounds through the design and procurement process and surfaces as cost during construction.
The Construction Experience Difference
Survey data is only as useful as the context that accompanies it. A point cloud file is a dataset. What matters is whether the person who captured it understood what they were looking at well enough to flag what the design team needs to know.
With 18 years of construction and architectural sales experience, Alturascope documentation visits are conducted by someone who knows what a structural engineer will want to see, what an M&E consultant will need to work around, and what conditions are worth flagging for the design team. That context — knowing what to look for and what to document — doesn't come with the scanner. It comes with the operator.
Every Alturascope documentation visit, regardless of deliverable type, includes a narrated conditions walkthrough with spoken commentary on what was found and what the design team should be aware of.
Frequently Asked Questions
What's the difference between .e57 and .rcp point cloud formats?
Both are industry-standard point cloud formats used in design workflows. .e57 is an open format that works across most CAD and BIM software including AutoCAD and Revit. .rcp is Autodesk's native format, optimised for use within the Revit and AutoCAD ecosystem. We can deliver in either format based on your team's software environment — just let us know at the briefing stage.
How accurate does a survey need to be for Revit modelling?
For most Revit as-built modelling, accuracy of 5–10mm is sufficient for structural and architectural elements. MEP coordination to this accuracy is typically adequate for schematic and design development stages. If the project involves prefabricated elements or tight tolerance fabrication, tighter accuracy requirements should be discussed at the survey brief stage.
Can you work from existing drawings to focus the survey?
Yes, and we'd encourage it. If existing drawings are available — even if known to be outdated — they help us focus capture effort on areas of uncertainty and identify discrepancies efficiently. Share whatever you have and we'll advise on how to structure the survey around it.
Do you provide the point cloud only, or a full package?
We can scope either. Point cloud delivery as a standalone is available for projects where the design team needs data and nothing else. Most projects benefit from the full documentation package — twin, conditions report, narrated walkthrough, asset schedule — alongside the point cloud, as different stakeholders use different parts of it.
The Bottom Line
Design teams working on existing buildings need data they can trust. The right survey methodology depends on what's being designed, not on what's cheapest or most convenient to deliver.
If you're unsure what level of survey accuracy your next project requires, we're happy to advise based on your design scope — before you commit to anything.
